224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯发电厂用汽车发心理气油经济增长性好: 现代化的气油设定程序，独具的STC、ESTC 等级设定程序，异常制作的缸筒边侧点燃室，高压低压输送气油，有效做雾化，点燃有效。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电站用打着机瞬态特性表现出色: 完全的打着机综合的设计，匹配康明斯独一无二的EFC设计，管理精度等级高，加载时长快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯并网发电用打着机升耗油率高: 大体设计的紧促.形状布设适当合理，自动运行平静。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷形号 QSNT. QSK19. QSK38. QSK50考虑我国非路途第三个一阶段及亚洲Tier2. Tier 3直接排放规范特殊要求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零部件可知性好， 发起机执行及运维养护等方便，的费用低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

电功率区域 Power Range   224-310KW技术要求 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L看上去尺寸 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净質量 Dry Weight   940kg

224-310KW康明斯来发电用打着机的优势特点：空间小， 再压缩比较高， 格珊氧气热处理加热，方便于通电，位移车载式电的好选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

打火机主要参数	选用电率(kW)Prime Power	紧急电机功率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
